NCASE M1 EVO is a reference layout, CNC Mini-ITX case at 15L in volume. MODEL M1EVO OVERVIEW M1EVO is a remaster of the Small Form Factor (SFF) icon M1 Classic. This product is made possible from the manufacturing help from FormD. With significant improvements in compatibility, thermal ceiling, build quality and value, M1EVO represents a material upgrade from the M1 Classic.Designed for three optimized build configurations, M1EVO represent the intersection of space optimization, thermal optimization, and premium build quality. MATERIALS 3-15mm Aluminum, CNC Machined and Anodized 1.0mm Steel, Powder Coated DIMENSIONS (CM) 16 x 25.6 x 36.6 VOLUME (L) 14.99 FRONT I/O Power Button 2x USB-A 1x USB-C 1x USB-C passthrough adapter MOTHERBOARD Mini-ITX, Deep-ITX, Mini-DTX, Micro-ATX CPU COOLER SUPPORT 1. M1-Classic Config: up to 135mm max height with 4-Slot GPU 2. M1-EVO Config: up to 135mm max height with 4-Slot GPU3. M1-VGPU Config: up to 50mm max height with 4-Slot GPU PCIe RISER 1. M1-Classic Config: Not Applicable 2. M1-EVO Config: Not Applicable 3. M1-VGPU Config: PCIe X16 4.0 GRAPHICS CARD SUPPORT 1. M1-Classic Config: up to 142 x 358.5mm, 4-slots thick 2. M1-EVO Config: up to 142 x 358.5mm, 4-slots thick 3. M1-VGPU Config: up to 165 x 358.5mm, 4-slots thick DRIVE SUPPORT 5x 3.5″ or 6x 2.5″ drives (based on components/hardware) FAN SUPPORT 6x 120mm, or 5x 140mm (based on components/hardware) LIQUID COOLING SUPPORT 1x 120 Radiator / AIO 1x 140 Radiator / AIO 1x 240 Radiator / AIO 1x 280 Radiator / AIO 2x 240 Radiator combo 2x 280 Radiator combo 3x 240 Radiator combo (requires a separate kit) 2x 280 + 240 Radiator combo (requires a separate kit) POWER SUPPLY SFX Power Supply SFX-L Power Supply ATX Power Supply (less than 140mm deep for GPUs longer than 270mm)
-
IQUNIX ZX-1 is CNC aluminium Mini-ITX case. The case is available in smaller air cooling version or slightly larger liquid cooling focused variant.
-
DAN A4-H2O is 11L Mini-ITX case. The case was designed by DAN Cases, then manufactured and distributed by Lian-Li.
-
MCPRUE Apollo S is currently on rev.3, which is 19.3L in volume. MODEL Apollo S 3.0 PRICE $439~$499 DIMENSIONS L: 374 x W: 185mm x H: 279mm (including case feet) VOLUME 19.3 Litres MATERIALS T6063 Aluminium (CNC) I/O USB 3.2 Type-C (Gen 1), USB 3.0 Type-C MOTHERBOARD Mini-ITX, Mini-DTX CPU COOLER 158mm EXPANSION SLOTS 3 GRAPHICS CARD L:333 x H:163 x W:83mm RISER N/A RADIATORS 280 (side) POWER SUPPLY SFX / SFX-L 2.5 / 3.5” DRIVES 3x 2.5” or 2x 2.5 + 1x 3.5” CASE FANS Top: 2x 140mm Only Front: 1x 120 / 140mm Side: 2x 140mm Only Rear: 1x 80 / 92mm Bottom: 2x 120x15mm
-
DAN C4-SFX v1 is EOL after single production run. The C4-SFX v2 case is targeted early 2024 release. The C4-SFX v2 will feature changes below: - new look - same layout as the v1 - slightly decreased volume - increased hardware compatibility - extra kits to customise colours - flat packed (easier for shipping and more economic)
-
Fractal Ridge is console layout Mini-ITX case at 12.6L in volume. MODEL Ridge PRICE US$129 / £129 DIMENSIONS L:74 x W:110 x H:395.4mm (including case stand) VOLUME 12.6 Litres MATERIALS Steel CASE I/O 2x USB 3.0 1x USB 3.1 Gen 2 Type-C 1x Audio/Microphone (combo jack) MOTHERBOARD Mini-ITX CPU COOLER 70mm EXPANSION SLOTS 3 GPU L:335mm (325mm with 2.5″ drive installed) W:57mm (82mm without 25mm thick fans installed) RISER PCIe 4.0 (included) RADIATORS 120mm (175mm GPU) / 280mm (without GPU) POWER SUPPLY SFX / SFX-L CASE FANS Top: 3x 80mm Side: 2x 120/140mm (2x 140x25mm included) 2.5″ / 3.5″ DRIVES 4x 2.5″ DUST FILTERS (INC) N
-
FreeFlow FF01 is a collaboration SFF case between NCASE & Streacom. The FF1 is designed for both horizontal and vertical placement and supports six different build configurations.
